Inclinometers » Cables and Connectors » EL-CON-99-3376-00-04 - Connector, M8, 4 pin female straight

EL-CON-99-3376-00-04 – Connector, M8, 4 pin female straight

An M8, 4 Pin female straight mating connector with solder bucket connections. Suitable for use with the HPS and Solar inclinometer sensors and IDS Display

EL-CON-99-3376-00-04 – Connector, M8, 4 pin female straight
1

Features

  • For cable OD: 3.5mm to 5.5mm
  • Screw connector locking system
  • IP67 Rated
  • Solder bucket type connections

Product Specification

Parameter Value Unit
Connector 1 M8, 4 Pin, female (straight) -
Screened No -
Used On HPS series inclinometer, Solar series incliniometer, IDS -
